Aluminum Profile Bolt, Connector For Extruded Profile

Aluminum Profile Bolt, Connector For Extruded Profile

Feature: used with connection plate
Material: Zinc Plated Steel
Color: Sliver Blue

Share:
Facebook
Twitter
LinkedIn

Aluminum Profile Bolt Connector

Stable and fixed screw connection for profiles. Invisible in the constructed frame.Excellent resistance to displacement and torsion.

For heavy-loaded frame, bolt connector is generally used together with die cast bracket to reinforce the structure.

Product Introduction

>>Dimensions

DescriptionFeature

Net Weight

(g)

Matching PGPart No.
Bolt, M6x205PG2020.2.09.01
Bolt, M8x2022PG3030.2.09.01
Bolt, M14x3032PG4040.2.09.01
PG4545.2.09.01
PG5050.2.09.01

Note 1: M14x30 bolt is suitable for Profile group with M14 core hole.

Note 2: Please choose the wrench that matches the bolts to avoid damage caused by operational errors.

Advantage

  • Bolt connector is the cost-optimized choice for fixed vertical connection between two profiles.
  • User-friendly, modular technology make it easy to assemble as well as reassemble.
  • Eco-friendly material, harmless to the users and easy for maintenance.
